PyQt5表格应用的详细Demo
PyQt5实现的一个表格应用的 demo。涉及的知识点：tableWidget 的基本使用，cell 内放置 widget，设置 cell 模式，分页，获取选中项目。
首先是 QtDesigner 设计, 一个 tablewidget，4个 pushbuttno：
<?xml version="1.0" encoding="UTF-8"?>
<ui version="4.0">
<class>MainWindow</class>
<widget class="QMainWindow" name="MainWindow">
<property name="geometry">
<rect>
<x>0</x>
<y>0</y>
<width>800</width>
<height>600</height>
</rect>
</property>
<property name="windowTitle">
<string>MainWindow</string>
</property>
<widget class="QWidget" name="centralwidget">
<widget class="QTableWidget" name="tableWidget">
<property name="geometry">
<rect>
<x>0</x>
<y>0</y>
<width>801</width>
<height>541</height>
</rect>
</property>
<property name="rowCount">
<number>5</number>
</property>
<property name="columnCount">
<number>11</number>
</property>
<row/>
<row/>
<row/>
<row/>
<row/>
<column/>
<column/>
<column/>
<column/>
<column/>
<column/>
<column/>
</widget>
<widget class="QWidget" name="horizontalLayoutWidget">
<property name="geometry">
<rect>
<x>0</x>
<y>540</y>
<width>801</width>
<height>31</height>
</rect>
</property>
<layout class="QHBoxLayout" name="horizontalLayout">
<item>
<widget class="QPushButton" name="btnLoad">
<property name="text">
<string>Load</string>
</property>
</widget>
</item>
<item>
<widget class="QPushButton" name="btnPre">
<property name="text">
<string>《Pre</string>
</property>
</widget>
</item>
<item>
<widget class="QPushButton" name="btnNext">
<property name="text">
<string>Next》</string>
</property>
</widget>
</item>
<item>
<widget class="QPushButton" name="btnDetail">
<property name="text">
<string>Detail</string>
</property>
</widget>
</item>
</layout>
</widget>
</widget>
<widget class="QStatusBar" name="statusbar"/>
</widget>
<resources/>
<connections/>
</ui>
生成的 ui 代码 tableWidgetDemo.py：
# -*- coding: utf-8 -*-
# Form implementation generated from reading ui file 'tableWidgetDemo.ui'
#
# Created by: PyQt5 UI code generator 5.6
#
# WARNING! All changes made in this file will be lost!
from PyQt5 import QtCore, QtGui, QtWidgets
class Ui_MainWindow(object):
def setupUi(self, MainWindow):
MainWindow.setObjectName("MainWindow")
MainWindow.resize(800, 600)
self.centralwidget = QtWidgets.QWidget(MainWindow)
self.centralwidget.setObjectName("centralwidget")
self.tableWidget = QtWidgets.QTableWidget(self.centralwidget)
self.tableWidget.setGeometry(QtCore.QRect(0, 0, 801, 541))
self.tableWidget.setRowCount(5)
self.tableWidget.setColumnCount(11)
self.tableWidget.setObjectName("tableWidget")
self.horizontalLayoutWidget = QtWidgets.QWidget(self.centralwidget)
self.horizontalLayoutWidget.setGeometry(QtCore.QRect(0, 540, 801, 31))
self.horizontalLayoutWidget.setObjectName("horizontalLayoutWidget")
self.horizontalLayout = QtWidgets.QHBoxLayout(self.horizontalLayoutWidget)
self.horizontalLayout.setContentsMargins(0, 0, 0, 0)
self.horizontalLayout.setObjectName("horizontalLayout")
self.btnLoad = QtWidgets.QPushButton(self.horizontalLayoutWidget)
self.btnLoad.setObjectName("btnLoad")
self.horizontalLayout.addWidget(self.btnLoad)
self.btnPre = QtWidgets.QPushButton(self.horizontalLayoutWidget)
self.btnPre.setObjectName("btnPre")
self.horizontalLayout.addWidget(self.btnPre)
self.btnNext = QtWidgets.QPushButton(self.horizontalLayoutWidget)
self.btnNext.setObjectName("btnNext")
self.horizontalLayout.addWidget(self.btnNext)
self.btnDetail = QtWidgets.QPushButton(self.horizontalLayoutWidget)
self.btnDetail.setObjectName("btnDetail")
self.horizontalLayout.addWidget(self.btnDetail)
MainWindow.setCentralWidget(self.centralwidget)
self.statusbar = QtWidgets.QStatusBar(MainWindow)
self.statusbar.setObjectName("statusbar")
MainWindow.setStatusBar(self.statusbar)
self.retranslateUi(MainWindow)
QtCore.QMetaObject.connectSlotsByName(MainWindow)
def retranslateUi(self, MainWindow):
_translate = QtCore.QCoreApplication.translate
MainWindow.setWindowTitle(_translate("MainWindow", "MainWindow"))
self.btnLoad.setText(_translate("MainWindow", "Load"))
self.btnPre.setText(_translate("MainWindow", "《Pre"))
self.btnNext.setText(_translate("MainWindow", "Next》"))
self.btnDetail.setText(_translate("MainWindow", "Detail"))
最后上实现代码：
from PyQt5 import QtWidgets, QtCore
import sqlite3
from tableWidgetDemo import Ui_MainWindow
class Window(QtWidgets.QMainWindow):
def __init__(self, parent=None):
super(Window, self).__init__(parent=parent)
self.ui = Ui_MainWindow()
self.ui.setupUi(self)
self.initStyle()
self.initConn()
self.currentPage = 1
self.ui.btnLoad.clicked.connect(lambda :self.loadData(1))
self.ui.btnDetail.clicked.connect(self.showDetail)
self.ui.btnPre.clicked.connect(lambda : self.loadData(self.currentPage - 1))
self.ui.btnNext.clicked.connect(lambda : self.loadData(self.currentPage + 1))
def closeEvent(self, event):
self.connection.close()
event.accept()
def initStyle(self):
horizontalHeader = ['CustomerID','FirstName','LastName','Company','Address','City','State','国籍','邮编','电话',"Action"]
self.ui.tableWidget.setHorizontalHeaderLabels(horizontalHeader)
def initConn(self):
self.connection = sqlite3.connect("mydb.db")
self.cur = self.connection.cursor()
def saveLine(self,id):
print("saveLine id %d" % id)
def delLine(self,id):
print("delLine id %d" % id)
def createInnerButton(self,id):
widget = QtWidgets.QWidget()
saveBtn = QtWidgets.QPushButton("Save")
saveBtn.setStyleSheet("background-color:DarkSeaGreen;border-style:outset;border-radius:3px")
saveBtn.setFixedSize(40,14)
saveBtn.clicked.connect(lambda: self.saveLine(id))
delBtn = QtWidgets.QPushButton("Del")
delBtn.setStyleSheet("background-color:LightCoral;border-style:outset;border-radius:3px")
delBtn.setFixedSize(40,14)
delBtn.clicked.connect(lambda: self.delLine(id))
layout = QtWidgets.QHBoxLayout()
layout.addWidget(saveBtn)
layout.addWidget(delBtn)
widget.setLayout(layout)
return widget
def showDetail(self):
select = self.ui.tableWidget.selectedItems()
if select:
print(select)
try:
print(select[0].text())
rs = ",".join([i.text() for i in select])
QtWidgets.QMessageBox.about(self, '你选择的项目', rs)
except Exception as e:
print(e)
else:
print("Nothing.")
def loadData(self, page = 1):
if page < 1:
QtWidgets.QMessageBox.about(self, '提示', "提示：已经到第一页了\t")
return
pageSize = 16
offset = (page - 1) * pageSize
query = "SELECT CustomerID,FirstName,LastName,Company,Address,City,State,Country,PostalCode,Phone FROM customers"
query += " limit %d offset %d" % (pageSize, offset)
self.cur.execute(query)
result = self.cur.fetchall()
if len(result) == 0:
QtWidgets.QMessageBox.about(self, '提示', "提示：没有下一页了\t")
return
self.currentPage = page
self.ui.tableWidget.setRowCount(0)
for row_number, row_data in enumerate(result):
self.ui.tableWidget.insertRow(row_number)
for colum_number, data in enumerate(row_data):
self.ui.tableWidget.setItem(row_number, colum_number, QtWidgets.QTableWidgetItem(str(data)))
temp = QtWidgets.QTableWidgetItem()
temp.setFlags(QtCore.Qt.ItemIsEnabled)
self.ui.tableWidget.setItem(row_number,10,temp)
actionItem = self.createInnerButton(row_data[0])
self.ui.tableWidget.setCellWidget(row_number,10,actionItem)
if __name__ == "__main__":
import sys
app = QtWidgets.QApplication(sys.argv)
w = Window()
w.show()
sys.exit(app.exec_())
最后，给出源码： PyQt5TableWidgetDemo.zip
最后修改于 2017-09-13
